19 Core 1-to-6 Loose Tail Power Fan-Out Cable, 1.5 m, 16 A Industrial Female Connectors, Socapex-Compatible Stage Breakout
Professional 19-core 1-to-6 loose tail power cable, 1.5 m, fitted with six 16 A industrial female connectors. Socapex-compatible fan-out for stage lighting, dimmer racks, and event power distribution. Rugged, flexible, and tour-ready.
- Product Details
- Technical Specification
Overview
This 19-core loose tail fan-out cable is designed to split a single 19-pin multicore feed into six independent power circuits. Each output is terminated with a 16 A industrial female connector, making it ideal for stage boxes, dimmer racks, LED walls, moving heads, and temporary event power networks. The 1.5 m tail length keeps connections close to distributiion panels while reducing on-stage cable clutter.
Key Features
19-Core Multicore Input: Compatible with standard 19-pin Socapex/entertainment power systems; supports up to six separate circuits through one rugged trunk.
1-to-6 Fan-Out: One main 19-pin end splits into six loose tails, each with a 16 A industrial female connector for direct appliance or distribution-box connection.
16 A Industrial Outlets: IEC 60309/CEE compliant. Default single-phase version 2P+E, 220–250 V, blue, 6h keyway, IP44; optional 3P+E or 3P+N+E for three-phase systems.
Heavy-Duty Tail Cable: Default 3×2.5 mm² fine-stranded copper per circuit; 3×1.5 mm² optional. Rubber or PVC flexible jacket available for touring, outdoor, and indoor use.
1.5 m Working Length: Short breakout length supplied as standard; trunk length and individual leg length can be customized.
Tour-Grade Build: Molded or assembled connectors, strain relief, clear circuit marking, and heat-shrink labels for fast setup and troubleshooting.
Typical Applications
Stage lighting power distribution and dimmer rack output tails
Concert, festival, theater, and broadcast temporary power
LED video wall and moving-light multicircuit feeds
Event distribution boxes, straight boxes, and rack PDUs
Rental staging where quick 19-pin-to-CEE conversion is required
Why Choose It
Instead of running six separate power cables, this loose-tail breakout carries all circuits in one 19-core trunk and fans out to six 16 A industrial females. It saves setup time, improves cable management, and uses standardized CEE/IEC 60309 connectors that are recognizable and safe for crew operations.
Parameter Details
Product type 19-core power loose tail / fan-out breakout, 1-to-6
Main input 19-pin Socapex-compatible connector (male or female by order)
Output quantity 6 circuits
Output connector 16 A industrial female, IEC 60309/CEE
Default output config 2P+E, 220–250 V AC, blue, 6h keyway, IP44
Optional output config 3P+E 380–415 V red 6h; 3P+N+E 380–415 V red 6h; 110–130 V yellow 4h
Per-circuit cable 3×2.5 mm² copper, fine-stranded (3×1.5 mm² optional)
Main trunk cable 19-core multicore; conductor size according to circuit design, commonly 18×power cores + spare/control core
Length 1.5 m standard per tail/trunk section; custom 0.5–50 m available
Rated current 16 A per output circuit
Rated voltage 220–250 V single-phase standard; other voltages by connector config
Insulation/jacket PVC or rubber (H07RN-F/Titanex-type on request), flame-retardant option
Operating temperature Approximately -15°C to +70°C depending on jacket; confirm rubber variant for extreme outdoor use
Ingress protection IP44 standard industrial connectors; IP67 option for 19-pin and CEE bodies
Bending radius Follow cable OD rule supplied by jacket spec; allow generous radius for multicore trunks
Marking Per-leg number/circuit ID, voltage, amp rating, and polarity/phase labels
Standards IEC 60309-1/-2 for industrial connectors; relevant IEC/EN cable standards; CE/RoHS documentation on request
Applications Stage, event, broadcast, theater, rental power distribution
